Mounting Piece For 2 Mod Left Hand Helical Rack, 24MM X 24MM X 200MM
Variation Not Available
GRSRH20/MOUNT
In Stock
£
83.53
Inc VAT
£
69.61
Ex VAT
Mounting Piece For 2 Mod Left Hand Helical Rack, 24MM X 24MM X 200MM | GRSRH20/MOUNT
Add to List
Remove from List
Add to Cart
SPECIFICATION
FURTHER INFO
- Helical Racks-with a helix angle of 19° 31′ 42″ Right hand
- Material – Steel C45
- 20° pressure angle
- Teeth – Hardened and ground HRC 50-55 all faces ground
- Quality Grade-6h 23 DIN3962/63/67
- Adjacent pitch error
0.006mm (3 Mod & under)
0.008mm (over 3 Mod)
Cumulative = Pitch error / 0.03mm (1000mm)
Part No. | Module | L | M | No. teeth | B | A | Height to pitch hp | c | N | R | V | d | D | T | P | S | d1 | (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SRH15/19/1C | 1.5 | 1000 | 6.7 | 200 | 19 | 19 | 17.50 0/-040 | 2 | 62.5 | 125 | 8 | 7 | 11 | 7 | 31.7 | 936.6 | 5.7 | 2.6 |
SRH20/24/1C | 2 | 1000 | 8.5 | 150 | 24 | 24 | 22.00 0/-027 | 2 | 62.5 | 125 | 8 | 7 | 11 | 7 | 31.7 | 936.6 | 5.7 | 4.1 |
SRH25/24/1C | 2.5 | 1000 | 8.5 | 120 | 24 | 24 | 21.50 0/-027 | 2 | 62.5 | 125 | 9 | 7 | 11 | 7 | 31.7 | 936.6 | 5.7 | 4.1 |
SRH30/29/1C | 3 | 1000 | 10.3 | 100 | 29 | 29 | 26.00 0/-034 | 2 | 62.5 | 125 | 9 | 10 | 15 | 9 | 35 | 930 | 7.7 | 5.9 |
SRH40/39/1C | 4 | 1000 | 13.8 | 75 | 39 | 39 | 35.00 0/-034 | 3 | 62.5 | 125 | 12 | 10 | 15 | 9 | 33.3 | 933.4 | 7.7 | 10.7 |
SRH50/49/1C | 5 | 1000 | 17.4 | 60 | 49 | 39 | 34.00 0/-034 | 3 | 62.5 | 125 | 12 | 14 | 20 | 13 | 37.5 | 925 | 11.7 | 13.1 |
SRH60/59/1C | 6 | 1000 | 20.9 | 50 | 59 | 49 | 43.00 0/-041 | 3 | 62.5 | 125 | 16 | 18 | 26 | 17 | 37.5 | 925 | 15.7 | 19.9 |
Please note: All dimensions subject to change. If a dimension is critical to your application please contact our Sales Department for confirmation.
For special or reworked racks please contact our Manufacturing Department for a quotation.
Helical Rack mounting pieces to assist assembly.
Left Hand Helix x 200 mm long ( without holes )
| Module | Mounting Piece |
|---|---|
| 1.5 Module | SRH15/MOUNT |
| 2.0 Module | SRH20/MOUNT |
| 2.5 Module | SRH25/MOUNT |
| 3.0 Module | SRH30/MOUNT |
| 4.0 Module | SRH40/MOUNT |
| 5.0 Module | SRH50/MOUNT |
| 6.0 Module | SRH60/MOUNT |
