| Code | Type | No. Teeth | Dp | De | Df | Dm | F | L | Bore(d) | No. Flanges | Gs |
|---|---|---|---|---|---|---|---|---|---|---|---|
| P10MXL025FB | 0FB | 10 | 6.47 | 5.97 | 10 | 10 | 7 | 16 | 3 | 2 | M2.5 |
| P12MXL025FB | 0FB | 12 | 7.77 | 7.26 | 11 | 11 | 7 | 16 | 3 | 2 | M2.5 |
| P14MXL025FB | 0FB | 14 | 9.07 | 8.58 | 12.5 | 12.5 | 7 | 16 | 3 | 2 | M2.5 |
| P15MXL025FB | 0FB | 15 | 9.70 | 9.19 | 13 | 13 | 7 | 16 | 3 | 2 | M2.5 |
| P16MXL025F | 0F | 16 | 10.35 | 9.84 | 15 | 15 | 8.5 | 16 | – | 2 | – |
| P16MXL025FB | 0FB | 16 | 10.35 | 9.84 | 14 | 14 | 7 | 16 | 3 | 2 | M2.5 |
| P18MXL025F | 0F | 18 | 11.64 | 11.12 | 16 | 16 | 8.5 | 16 | – | 2 | – |
| P18MXL025FB | 0FB | 18 | 11.64 | 11.12 | 15 | 15 | 7 | 16 | 3 | 2 | M2.5 |
| P20MXL025F | 0F | 20 | 12.94 | 12.43 | 16 | 16 | 8.5 | 16 | – | 2 | – |
| P20MXL025FB | 0FB | 20 | 12.94 | 12.43 | 16 | 16 | 7 | 16 | 3 | 2 | M2.5 |
| P22MXL025F | 1F | 22 | 14.23 | 13.72 | 17 | 10 | 11 | 16 | 3 | 2 | – |
| P22MXL025FB | 0FB | 22 | 14.23 | 13.72 | 18 | 18 | 7 | 16 | 3 | 2 | M2.5 |
| P24MXL025F | 1F | 24 | 15.52 | 15.01 | 20 | 10 | 11 | 16 | 3 | 2 | – |
| P24MXL025FB | 0FB | 24 | 15.52 | 15.01 | 19 | 19 | 7 | 16 | 3 | 2 | M2.5 |
| P28MXL025F | 1F | 28 | 18.11 | 17.6 | 25 | 11 | 11 | 16 | 3 | 2 | – |
| P30MXL025F | 1F | 30 | 19.40 | 18.90 | 25 | 12 | 11 | 16 | 4 | 2 | – |
| P32MXL025F | 1F | 32 | 20.70 | 20.19 | 26 | 14 | 11 | 16 | 4 | 2 | – |
| P36MXL025F | 1F | 36 | 23.29 | 22.78 | 28 | 16 | 11 | 16 | 4 | 2 | – |
| P40MXL025F | 1F | 40 | 25.87 | 25.37 | 32 | 18 | 11 | 16 | 4 | 2 | – |
| P42MXL025F | 1F | 42 | 27.17 | 26.67 | 32 | 18 | 11 | 16 | 5 | 2 | – |
| P44MXL025F | 1F | 44 | 28.46 | 27.95 | 36 | 18 | 11 | 16 | 5 | 2 | – |
| P48MXL025 | 2 | 48 | 31.05 | 30.54 | – | 20 | 11 | 16 | 5 | 0 | – |
| P60MXL025 | 2 | 60 | 38.81 | 38.30 | – | 24 | 11 | 16 | 5 | 0 | – |
| P72MXL025 | 2 | 72 | 46.57 | 46.06 | – | 25 | 11 | 16 | 6 | 0 | – |
Dimensions shown in millimetres
Please note:All dimensions subject to change.Pulleys may be Bored or Unbored.
If a dimension is critical to your application please contact our Sales Department for confirmation.
For special or reworked pulleys please contact our Manufacturing Department for a quotation.
