| a | b | c | d | e | f | h | a34 | a38 |
|---|---|---|---|---|---|---|---|---|
| 9.7 | 8.5 | 8 | 12 | 8 | 2 | 11 | P<=80 | P>80 |
| Type | Diameter P (mm) | Diameter O (mm) | Style | Bush | Bore ø max. | E | F | J | K | L | M | N |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SPZ50/1 | 50 | 54 | 9 | 1008 | 25 | – | 37 | 26 | 12 | 25 | – | – |
| SPZ56/1 | 56 | 60 | 9 | 1008 | 25 | – | 37 | 32 | 12 | 25 | – | – |
| SPZ60/1 | 60 | 64 | 1 | 1008 | 25 | – | 22 | – | – | 22 | – | – |
| SPZ63/1 | 63 | 67 | 1 | 1108 | 28 | – | 16 | – | – | 22 | 6 | 56 |
| SPZ67/1 | 67 | 71 | 1 | 1108 | 28 | – | 16 | – | – | 22 | 6 | 50 |
| SPZ71/1 | 71 | 75 | 1 | 1108 | 28 | – | 16 | – | – | 22 | 6 | 50 |
| SPZ75/1 | 75 | 79 | 1 | 1108 | 28 | – | 16 | – | – | 22 | 6 | 50 |
| SPZ80/1 | 80 | 84 | 1 | 1210 | 32 | – | 16 | – | – | 25 | 9 | 75 |
| SPZ85/1 | 85 | 89 | 1 | 1210 | 32 | – | 16 | – | – | 25 | 9 | 80 |
| SPZ90/1 | 90 | 94 | 1 | 1210 | 32 | – | 16 | – | – | 25 | 9 | 80 |
| SPZ95/1 | 95 | 99 | 1 | 1210 | 32 | – | 16 | – | – | 25 | 9 | 85 |
| SPZ100/1 | 100 | 104 | 1 | 1210 | 32 | – | 16 | – | – | 25 | 9 | 85 |
| SPZ106/1 | 106 | 110 | 1 | 1610 | 42 | – | 16 | – | – | 25 | 9 | 92 |
| SPZ112/1 | 112 | 116 | 1 | 1610 | 42 | – | 16 | – | – | 25 | 9 | 92 |
| SPZ118/1 | 118 | 122 | 1 | 1610 | 42 | – | 16 | – | – | 25 | 9 | 92 |
| SPZ125/1 | 125 | 129 | 1 | 1610 | 42 | – | 16 | – | – | 25 | 9 | 92 |
| SPZ132/1 | 132 | 136 | 1 | 1610 | 42 | – | 16 | – | – | 25 | 9 | 92 |
| SPZ140/1 | 140 | 144 | 1 | 1610 | 42 | – | 16 | – | – | 25 | 9 | 92 |
| SPZ150/1 | 150 | 154 | 1 | 1610 | 42 | – | 16 | – | – | 25 | 9 | 92 |
| SPZ160/1 | 160 | 164 | 1 | 1610 | 42 | – | 16 | – | – | 25 | 9 | 92 |
| SPZ170/1 | 170 | 174 | 1 | 1610 | 42 | – | 16 | – | – | 25 | 9 | 92 |
| SPZ180/1 | 180 | 184 | 7 | 1610 | 42 | 5 | 16 | 152 | – | 25 | 9 | 92 |
| SPZ190/1 | 190 | 194 | 7 | 1610 | 42 | 12 | 16 | 162 | – | 25 | 9 | 92 |
| SPZ200/1 | 200 | 204 | 7 | 2012 | 50 | 10 | 16 | 171 | – | 32 | 16 | 112 |
| SPZ224/1 | 204 | 208 | 7 | 2012 | 50 | 15 | 16 | 195 | – | 32 | 16 | 112 |
| SPZ250/1 | 250 | 254 | 4 | 2012 | 50 | – | 16 | 221 | 8 | 32 | 8 | 112 |
| SPZ280/1 | 280 | 284 | 4 | 2012 | 50 | – | 16 | 251 | 8 | 32 | 8 | 112 |
| SPZ315/1 | 315 | 319 | 4 | 2012 | 50 | – | 16 | 286 | 8 | 32 | 8 | 112 |
| SPZ355/1 | 355 | 359 | 4 | 2012 | 50 | – | 16 | 326 | 8 | 32 | 8 | 112 |
| SPZ400/1 | 400 | 404 | 4 | 2012 | 50 | – | 16 | 326 | 8 | 32 | 8 | 112 |
| SPZ450/1 | 450 | 454 | 4 | 2012 | 50 | – | 16 | 326 | 8 | 32 | 8 | 112 |
